• Brackets for mounting AVENTOS HL top in a
corner appliance garage face frame application
• Set includes L/R bracket and
M4 x 30 mm lift mechanism mounting
screws (qty 12)
Minimum recess = 12.5 (1/2")
Item No. List Set
$53.76
AVENTOS HL top Lift Up System - Appliance Garage Application
Wood or Wide Aluminum Door for Panel and Face Frame Applications
5 separate items are required to complete unit:
Arm assembly set, lift mechanism set, cross stabilizer rod, hardware set and cover set. Order screws
separately for hardware set. Optional corner bracket set is available separately. NOTE: a pozidrive
bit is required to make necessary adjustments .
For complete specifications order Blum catalog
or visit
SERVO-DRIVE for AVENTOS HL see page 307.
11/24
Order a cover set
Set No. List Set
$47.50
$47.50
$47.50
Minimum Cabinet Depth: 264 (10-3/8")
Cover Set includes
1 ea. LH/RH cover plate
2 ea. cover caps
3
Set includes (2) lift mechanisms and (8) #7 x 35mm (1-3/8")
wood screws.
Set No. Cabinet Height List Set
300-389 (11-3/4 to 15-1/4") $207.76
390-580 (15-1/4 to 22-3/4") $222.80
Aluminum, 1076 mm (42-5/16").
Cut-to-size=Interior cabinetwidth - 113mm(4-7/16").
Item No. List Ea.
$40.84
Assembly Set includes
2 ea. arm assembly
2 ea. cross stabilizer cover caps
1 ea. cross stabilizer rod adapter
1 ea. cross stabilizer length adapter Connecting Set includes
2 ea. cross stabilizer cover caps
2 ea. cross stabilizer rod adapter
1 ea. cross stabilizer connecting piece
1 ea. cross stabilizer fixing
Set No. Cabinet Height
Door
Weight List Set
300-339 (11-3/4 to 13-1/4") 3-19 lb. $146.64
340-389 (13-3/8 to 15-1/4") 3-22 lb. $149.64
390-540 (15-1/4 to 21-1/4") 4-27 lb. $154.16
480-580 (18-7/8 to 22-3/4") 5-30 lb. $170.68
Order screws separately (8 required)
Item No. Door Description List
MCFPT586-1C Wood #6x5/8" FHPH $4.84c
300 (11-13/16") - 580 (22-13/16")
door range
up to 1828 (72")
Order an arm assembly set
Order a lift mechanism set
Order a cross stabilizer rod
Order a hardware set
Standard hardware set includes 2 arm as-
sembly mounting plates.
Set No. List Set
B20S4200 $10.04
Special application: For large overlay on
5-piece doors, includes (2) mounting plates
with brackets, screws included.
Set No. List Set
B20S4F01 $22.92
1
2
4
5
Light Gray (HG) Dark Gray (TG) Silk White (SW)
Order a cross stabilizer connecting set (optional)
Bracket Set for face frame application (optional)
Don't know the door weight?
Call us...we can help! ?
Interior cabinet width >1190 (46-7/8")
Cutting for 5: Interior cabinet width ÷ 2 (1/16") - 105 (4-1/8")
Item No. List Ea.
$37.24
