Charles McMurray Co. 2023 Catalog

303 / 1645

Calculate the power factor to determine the required lift mechanism for your application. See formula below.
Note: Face frame cabinets require B22K6001 brackets (special order) to mount the lift mechanisms.
Power factor (PF) = cabinet height (") x door weight (lbs.) including twice the handle weight.
Power
Factor
Opening
Angle Set No. List Set
36-139 107° $169.76
80-240 107° $169.76
150-450 100° $180.46
270-781 100° $207.24
Maximum front weight is 39 lbs. for two lift mechanisms.
Minimum Cabinet Depth = 187mm (7-3/8")
For complete specifications visit
TIP-ON for AVENTOS HK top Lift System
Wood or Wide Aluminum Door for Panel and Face Frame Applications
4 separate items are required to complete unit:
Lift mechanism set, TIP-ON mechanism, hardware set and cover set. Order
screws separately for hardware set. NOTE: a torx T20 screwdriver is required
to make necessary adjustments.
Works for both overlay and inset applications.
Gray nylon.
Set No. Description List Set
For standard doors $12.64
For large doors $15.82
250 (10") - 610 (24")
door range
381 (15") - 1828 (72")
Order a hardware set
Determine the power factor for the application
Order a lift mechanism set
Order a TIP-ON mechanism set Order a cover set
Set includes
2 ea. Lift mechanisms
8 ea. #7 x 35mm (1-3/8") wood screws
1 ea. Positioning template
Cover Set includes
1 ea. LH/RH cover plate
2 ea. cover caps
Set No. Finish List Set
B22K8000HG Light Gray $30.70
Silk White $32.64
B22K8000TG Dark Gray $32.64
Light Gray Silk White
Dark Gray
1
2 4
5 3
Order screws separately (8 required)
Item No. Door Description List
Wood #6x5/8" FHPH $4.84c
Standard hardware set includes 2 arm
assembly mounting plates.
Set No. List Set
$10.04
Special application: For large overlay
on 5-piece doors, includes 2 mounting
plates with brackets. Use (4) countersunk
self-tapping screws included (660.0950).
Set No. List Set
$22.92
Don't know the door weight?
Call us...we can help! ?
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
AVENTOS & LIFTS
800.533.0533 303 Prices subject to change without notice.
McMurray.com
