SERVO-DRIVE Opening Feature For AVENTOS
Completely safe, even when closing
Even when the switch has just been pressed for closing — the closing procedure is halted immediately if the user again reaches
into the cabinet and/or an object is placed between the cabinet and the door.
Completely under control
Even though lift systems open and close automatically, the motion can be interrupted at any time. In addition, lift systems with
SERVO-DRIVE for AVENTOS can also be easily opened and closed manually at anytime, e.g. when there is a power outage.
Completely synchronized
Up to three drive units can be set for synchronized motion. Synchronization is ideal for multiple cabinets that share one wide door.
Collision avoidance
For corner applications, it is especially important that lift system fronts do not open simultaneously. Thanks to the “collision
avoidance” function, you can set drive units so that only one front opens at a time.
For complete specifications order Blum catalog
B-SERVODRIVE for AVENTOS
or visit
www.blum.comAVENTOS lift systems open with just a light touch — and then close again with the
press of a button. An inspiring feature that is certain to impress, thanks to SERVO-
DRIVE for AVENTOS, the new electrical opening support for lift systems. After lift
mechanism installation and adjustment, SERVO-DRIVE components are attached to
the lift mechanism and cabinet.
A simple touch of the switch closes
the door. The BLUMOTION soft-
close feature ensures silent and
effortless closing.
A light touchon the front of the cabinet
using your hand or elbow is all it takes
toopen the door. Even large andheavy
doors open effortlessly.
You will need 5-7 separate items to complete the application:
AVENTOS Lift System - (see pages 295-301)
Lift Mechanism
Telescopic Arm (HF Series only)
Hardware Set
Cross Stabilizer Rod (HL Series only)
SERVO-DRIVE System - (see pages 306-308)
SERVO-DRIVE Unit
SERVO-DRIVE Power Supply*
Cover Set
Arm Assembly Set (HL Series only)
*The power supply may power more than one unit, depending on layout.
Step One
Order the AVENTOS lift system (see pages 295-301
for ordering information).
Step Two
Order the SERVO-DRIVE components for the
appropriate AVENTOS system.
