Using the power factor, you can calculate the number of required lift mechanisms. The power factor required depends on the door
weight (including twice the handle weight) and cabinet height. NOTE: Additional lift mechanism recommended for wide cabinets.
AVENTOS HKi Compact Integrated Door Lift System
Wood or Aluminum Frame Door for Narrow or Wide Frameless Applications
Two brackets required per door. 20 ea. per box. Sold per ea.
Set No. Description Finish List Ea.
List Ea.
20
EXPANDO Onyx Black $26.62 $22.42
Screw-on Onyx Black $29.26 $24.64
3 separate items are required to complete unit:
Lift mechanism set, hardware set, and cover set*. Screws included with hardware set. NOTE:
a pozidrive bit , torx T8 and T20 screwdriver are required to make
necessary adjustments. *Cover set required for semi-integrated installation only
Order a cover set
Order optional accessories
Set No. List Set
$93.26
$93.26
$93.26
Set No. List Set
$339.60
Set No. List Set
$330.34
Set No. List Ea.
$411.72
Power Factor Set No. Finish List Set
37-142 Onyx Black $953.68
82-246 Onyx Black $953.68
152-458 Onyx Black $970.16
229-686 Onyx Black $1,011.30
Set includes two lift mechanisms
Opening angle = 107°
Pre-milled cabinet side panels
Set includes two MDF raw boards with
spacers for transport.
(23-5/8"H x 17-11/16"W x 3/4"D)
Milling template set
Includes: (1) template for lift mechanism,
(1) template for insert panel,
and (1) Baseplate
Copy milling cutter (19 mm)
For use with milling template set.
EXPANDO (5 mm)
For wood doors
Screw-on
For narrow or wide
aluminum frames
(screws included)
Minimum Inside Cabinet Depth: 271 (10-11/16")
Minimum Side Panel Thickness: 16 (5/8")
Power factor (PF) = cabinet height (") x door weight (lbs.) including twice the handle weight.
Full integration of lift mechanism Semi-integration of lift mechanism
Order mounting brackets
Determine the power factor for the application
Order a lift mechanism set
Cover Set includes
1 ea. LH/RH cover plate
2 ea. cover caps
Silk White (SW) Dark Gray (TG)
1
2
3
4
5
152 (6-3/8") - 610 (24") up to 1828 (72")
door range
(For semi-integrated installation only)
(For full integration installation only)
(For full or semi-integration installation)
3 3
2
3 3
2
4
