Charles McMurray Co. 2023 Catalog

310 / 1645

AVENTOS Accessories
AVENTOS Template
For face frame adapter plates. Frame thicknesses of 5/8" to 1".
Item No. List Ea.
$223.76
Use of a bit holder and pozi bit insert is recommended when
adjusting the tension of the lift mechanism.
Item No. Description List Ea.
Pozi Bit $2.54
Bit Holder $22.48
For AVENTOS HK-S
Restricts the opening angle of the door. Prevents the door from
hitting an object above, or to keep the handle within reach on
very high cabinets.
Two required per lift mechanism set.
Item No. Angle List Ea.
75° $2.78
100° $2.78
For complete specifications order Blum catalog
or visit
Use to pre-bore for AVENTOS lift mechanism locating pins. Can
also be used for pre-boring cabinet profiles and BLUMOTION
for doors and TIP-ON for doors adapter plates. Calibrated scale
for accurate setting. Includes 2 stop collars.
Item No. List Ea.
$219.90
Boring Template for AVENTOS SERVO-DRIVE Switch
PlateMate
Clamp assembly for secure boring of
AVENTOS SERVO-DRIVE switch.
Includes 35mmbit and two torx driver bits.
Item No. List Ea.
$721.88
75° 100°
Stabilizer Rod Connecting Set
For AVENTOS HL top
Cut rods to: Interior cabinet width - 113 mm (4-7/16")
Connecting Set includes
2 ea. cross stabilizer cover caps
2 ea. cross stabilizer rod adapter
1 ea. cross stabilizer connecting piece
1 ea. cross stabilizer fixing
Set No. List Set
$37.24
Interior cabinet width >1190 (46-7/8")
Cutting for 5: Interior cabinet width ÷ 2 (1/16") - 105 (4-1/8")
11/24
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
AVENTOS & LIFTS
800.533.0533 310 Prices subject to change without notice.
