SLS-ELAN Easy Lift-Up Stay

Slim design and installation

location maximize the space

inside the cabinet.

Door Weight Range Table (lbs)

Door

Ht.*

Single Use

Pair Use

Medium Duty Heavy Duty Medium Duty Heavy Duty

Min Max Min Max Min Max Min Max

12"

8.0 10.8 10.8 14.5 16.0 21.7 21.7 29.0

13"

7.4 10.0 10.0 13.4 14.8 20.0 20.0 26.8

14"

6.9 9.3 9.3 12.4 13.7 18.6 18.6 24.9

15"

6.4 8.7 8.7 11.6 12.8 17.3 17.3 23.2

16"

6.0 8.1 8.1 10.9 12.0 16.3 16.3 21.8

17"

5.6 7.6 7.6 10.2 11.3 15.3 15.3 20.5

18"

5.3 7.2 7.2 9.7 10.7 14.4 14.4 19.3

19"

5.1 6.8 6.8 9.2 10.1 13.7 13.7 18.3

20"

4.8 6.5 6.5 8.7 9.6 13.0 13.0 17.4

21"

4.6 6.2 6.2 8.3 9.1 12.4 12.4 16.6

22"

4.4 5.9 5.9 7.9 8.7 11.8 11.8 15.8

23"

4.2 5.7 5.7 7.6 8.3 11.3 11.3 15.1

24"

4.0 5.4 5.4 7.3 8.0 10.8 10.8 14.5

25"

3.8 5.2 5.2 7.0 7.7 10.4 10.4 13.9

26"

3.7 5.0 5.0 6.7 7.4 10.0 10.0 13.4

27"

3.6 4.8 4.8 6.4 7.1 9.6 9.6 12.9

28"

3.4 4.6 4.6 6.2 6.9 9.3 9.3 12.4

* Single or pair use depending on door size and weight.

Easy Installation

Adjustment

• For UPWARD-OPENING flap door with concealed,

piano, butt or drop hinges

• Designed to provide effortless opening and hold

door in closed and opened position

• Damper equipped for soft & silent closing

• Single or pair use allows a wide range of door

sizes and weights

• Handed left or right

• Aluminum and steel with light grey plastic

Easy installation: align the body

to the edge of the cabinet.

3 functions on 1 Stay!

1. Lift-assist

2. Free stop

3. Soft-close

Item No.

Description List Ea. List Ea. 20

Heavy Duty LH $127.10 $106.68

Heavy Duty RH $127.10 $106.68

Medium Duty LH $127.10 $106.68

Medium Duty RH $127.10 $106.68

*19mm overlay use shown

(left-hand side mounting)

SLS-ELAN Soft-Closing Lid-Stays
