Lapcon Vertical Swing Lift-Up Mechanisms
• Unique mechanism will help lift doors and hold at the open position
• Adjustable arm mounting plate
• Patented LAPCON technology provides a smooth and quiet motion
• Successfully passed 30,000 open/close private cycle tests
• Designed to operate at room temperature 32° - 104°F
• Recommended Door Size and Weight:
Width 23-5/8" to 35-7/16"
Height 15-23/64" to 17-23/32"
Weight 6.2 to 12.8 lbs.
• Includes steel screws
• Steel with nickel finish and gray plastic
Set No. Door Weight Box List Set
List Set
Full Box
6.2 - 8.4 lbs. 5 $298.04 $250.14
8.4 - 10.6 lbs. 5 $298.04 $250.14
10.6 - 12.8 lbs. 5 $298.04 $250.14
Guide Bar Length
Door Type Cabinet Width (mm)
600 (23-5/8") 900 (35-7/16")
Solid Wood Door 535 (21-1/16") 835 (32-7/8")
Frame Door 551 (21-3/4") 851 (33-1/2")
*SLUB-835 (835 mm (32-7/8") guide bar included unless specified.
Projection: 4" including door
