Order screws separately.
Item No. Door Type Description List
(12 required) Wood #6 x 5/8" $4.64c
(16 required) Aluminum #7 x 13mm $0.38ea
Calculate the power factor to determine the required lift mechanism for your application. See formula below.
Note: Face frame cabinets require B22K6001 brackets (special order) to mount the lift mechanisms.
Power factor (PF) = cabinet height (") x door weight (lbs.) including twice the handle weight.
Power
Factor
Opening
Angle Set No. List Set
36-139 107° $169.76
80-240 107° $169.76
150-450 100° $180.46
270-781 100° $207.24
Maximum front weight is 39 lbs. for two lift mechanisms.
Minimum Cabinet Depth = 187mm (7-3/8")
For complete specifications visit
TIP-ON for AVENTOS HK top Lift System
Wood or Wide Aluminum Door for Panel and Face Frame Applications
4 separate items are required to complete unit:
Lift mechanism set, TIP-ON mechanism, hardware set
and cover set. Order screws separately for hardware set.
NOTE: a torx T20 screwdriver is required to make
necessary adjustments.E
Works for both overlay and inset applications.
Gray nylon.
Set No. Description List Set
For standard doors $12.64
For large doors $15.82
Don't know the door weight?
Call us...we can help!
250 (10") - 610 (24")
door range
381 (15") - 1828 (72")
Step 4 - order a hardware set
Step 1 - Determine the power factor for the application
Step 2 - order a lift mechanism set
Step 3 - order a TIP-ON mechanism set
Step 5 - order a cover set
Set includes
2 ea. Lift mechanisms
8 ea. #7 x 35mm (1-3/8") wood screws
1 ea. Positioning template
Standard hardware set includes 2 arm
assembly mounting plates.
Set No. List Set
$10.04
Special Application
2 mounting plates with brackets for large
overlay on 5-piece doors with face frame
application.
Set No. List Set
$22.92
Cover Set includes
1 ea. LH/RH cover plate
2 ea. cover caps
Set No. Finish List Set
B22K8000HG Light Gray $30.70
Silk White $32.64
B22K8000TG Dark Gray $32.64
Light Gray Silk White
Dark Gray
