Few parts — many applications
TIP-ON for AVENTOS is an excellent solution for handleless doors. The mechanical opening feature allows you to simply push the
door front to open. For a secure close, simply press lightly on the front and the catch plate attached to the inside of the door front.
It's that easy. TIP-ON for AVENTOS HK top and HK-S provides a unique solution for kitchen and office applications.
Easy installation and adjustment
The three-dimensional adjustment feature
enables doors to be precisely aligned.
TIP-ONforAVENTOSHK top&HK-S
A perfect solution for handleless lift ap-
plications. TIP-ONmechanical support
systemmakes openingdoors effortless.
Numerous design options
AVENTOS HK top & HK-S can be used
in wall cabinets, in a pantry or above a
refrigerator or other appliance.
TIP-ON for AVENTOS HK top and HK-S Stay Lift Systems
Wood or Wide Aluminum Door for Panel and Face Frame Applications
AVENTOS HK top Door and hardware clearance
Z = door height x 0.29 + door thickness minus top panel thickness
Planning tools available at
www.blum.comZ = door height x .29 minus
15
+ door thickness
AVENTOS HK-S Door and hardware clearance
TIP-ON for AVENTOS specifications
*
for large doors
Screw-on catch plate-
Pre-boringØ2.5mmcoun-
tersunk pilot holes are
required.
Lift Mechanism Clearance
HK
HK-S
