D Set includes:
Power supply
Wall mount bracket
Three-prong power cord
Cable connector
Cable end protector (qty 3)
Cable clips (qty 10)
19 feet universal cable
Technical information
Set No. List Set
$618.12
Supplies power to a single
SERVO-DRIVE unit. Includes the
12W power supply with 44" cord.
Item No. List Ea.
$228.06
For multiple lift systems
For single lift system
SERVO-DRIVE Opening Feature
For AVENTOS HL
After lift mechanism installation and adjustment,
SERVO-DRIVE components are attached to the lift mechanism and cabinet.
Step 1 - Order the appropriate AVENTOS lift
mechanism, cross stabilizer rod* and hardware set
for your application (see page 299).
A Set includes:
Drive unit
60" universal cable
Cable connector
Cable end protector (qty 2)
Set No. List Set
$880.44
B Set includes:
SERVO-DRIVE cover plate (left)
Cover plate (right)
Non-handed cover cap (qty 2)
SERVO-DRIVE switches (qty 2)
Ø5 mm Blum distance bumper (qty 4)
Color: light gray, silkwhite, or dark gray
Set No. List Set
$294.00
$294.00
$294.00
Step 5 - Order a Power Supply
Step 4 - Order an Arm Assembly Set
C Set includes:
SERVO-DRIVE arm assembly (left)
Standard arm assembly (right)
Stabilizer rod cover cap (qty 2)
NOTE: Stabilizer rod cutting dimension for SERVO-DRIVE ap-
plication is length = interior cabinet width -164 (6-7/16").
Item No. Cabinet Height List Set
450 to 580 (17-11/16" to 22-13/16") $208.32
*NOTE: Cutting dimension for stabilizer rod with SERVO-
DRIVE inside cabinet width -164 mm (6-3/8").
Step 2 - Order a SERVO-DRIVE Set
Step 3 - Order a Cover Set
B
B
B
B
A
C
Dark Gray
Silk White
Light Gray
11/21
Finishes
HG Light Gray
SW Silk White
TG Dark Gray
