Charles McMurray Co. 2021 Catalog

311 / 1590

• Unique swing-down mechanism will hold doors at the open position
• Sleek & compact design
• Adjustable arm mounting plate
• Patented LAPCON technology provides a smooth and quiet motion
• Recommended Door Size and Weight:
Width: 23-5/8" - 35-7/16"
Height: 14-1/8" - 15-3/4"
Weight: 6.6 - 11 lbs.
• Designed to operate at room temperature 32-104°F
• Includes steel screws
• Steel with nickel finish and gray plastic
Item No. Door Weight Box List Set
List Set
Full Box
6.6 - 8.8 lbs. 5 $471.64 $399.70
8.8 - 11 lbs. 5 $471.64 $399.70
Lapcon Vertical Swing-Down Mechanisms
Guide Bar Length
Door Type Cabinet Width (mm)
600 (23-5/8") 900 (35-7/16")
Solid Wood Door 535 (21-1/16") 835 (32-7/8")
Frame Door 551 (21-3/4") 851 (33-1/2")
*SLUB-835 (835 mm (32-7/8") guide bar included unless specified.
Easy Installation
Space Saving
DECORATIVE HARDWARE
CABINET HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
AVENTOS & LIFTS
800.533.0533 2021 1946 311 Prices subject to change without notice.
