Charles McMurray Co. 2021 Catalog

313 / 1590

• Holds lid or panel in fully opened position
• Lift up lid to release
• Non-handed, can be installed on left or right side
• Can be installed individually or in pairs
• Load capacity 33 lbs. each
• Satin stainless steel finish
No. L1 L2 L3 A B C Door Height
148 121 129 133 62 195 250-350
(5-53/64") (4-3/4") (5-5/64") (5-15/64") (2-7/16") (7-43/64") (9-27/32" - 13-25/32")
185 158 166 170 100 270 320-500
(7-9/32") (6-7/32") (6-17/32") (6-11/16") (6-11/16") (10-5/8") (12-19/32" - 19-11/16")
With Concealed Hinge With Piano/Butt Hinge
Lid stay must be installed parallel to the sidewall
Screws not included. Recommended: Panhead #6
Item No. Opening Box List Ea. List Ea. 10
66-75° 10 $73.26 $59.80
82-90° 10 $85.50 $69.80
Lid Stays
Stainless Steel
