Charles McMurray Co. 2021 Catalog

317a / 1590

Pneumatic Lid Stays
Suitable for wood or aluminum frame door. Silver painted/
chrome-plated steel finish. (1) Cabinet mounting bracket,
(1) bracket each for wood and aluminum doors, and screws
included.
Item No.
Weight
Capacity Box List Ea. List Ea. 10
18 lbs. 10 $48.28 $35.50
20 lbs. 10 $48.28 $35.50
22 lbs. 10 $48.28 $35.50
Opening angle A B C
75° 260 mm (10-1/4") 80 mm (3-1/8") 25 mm (1")
90° 238 mm (9-3/8") 80 mm (3-1/8") 25 mm (1")
110° 215 mm (8-9/16") 70 mm (2-3/4") 25 mm (1")
(Dimensions when using hinges for
full overlay mounting.)
08/22
Cabinet
mounting bracket
Mounting bracket
for wood door
Mounting bracket
for aluminum door
Cabinet
mounting
bracket
Mounting
bracket for
aluminum doors
Mounting
bracket for
wood doors
