Charles McMurray Co. 2021 Catalog

318a / 1590

Heavy Duty Lift-Assist Damper Sets with Angle Stopper
(Piano Hinge Included)
• Lift-assist feature with light opening helps user raise door
• Soft-close damper has adjustable closing speed
• Damper function engages at low angles (does not need to
be fully opened to soft-close)
• Stopper holds panel at 95° to prevent over-rotation
• Surface-mounting allows retrofit into existing countertop
passages
• Compatible with butt and piano hinges only, may not be
used with concealed hinge
• LSN-C Piano Hinge included with set
For panel thickness 30-50 mm (1-3/16" to 2"). Sold per each.
Item No.
Min. Torque
lbs./in.
Max. Torque
lbs./in. List Ea.
LADH-35 221 309 $489.44
309 442 $519.12
For use on wood, not suitable for sheet
metal or installations with hole pitch
limitations.
LSN-C Piano Hinge (included)
Stainless steel, 600 mm long (23-5/8")
x 38 mm wide (1-1/2"), can be cut to
usable length.
This product is not designed to support the weight of
the door in closed position
12/21
Available in white by special order
