Charles McMurray Co. 2021 Catalog

309 / 1590

AVENTOS Accessories
AVENTOS Template
Use to pre-bore for AVENTOS lift
mechanism locating pins. Can also
For face frame adapter plates. Frame thicknesses of 5/8" to 1".
Item No. List Ea.
$223.76
Use of a bit holder and pozi bit insert is recommended when
adjusting the tension of the lift mechanism.
Item No. Description List Ea.
Pozi Bit $2.54
Bit Holder $21.62
Stabilizer Rod Connector Set
For AVENTOS HL
Cut rods to:
Standard
Application Inside cabinet width divided by 2 minus 147mm
Servodrive
Application Inside cabinet width divided by 2 minus 165mm
Includes connector rod, 2 oval cover caps and topmounting hook.
Item No. List Set
$51.76
Opening Angle Restriction Clips
For AVENTOS HF
For AVENTOS HK-S
Restricts the opening angle of the door. This may be useful for
cabinets with large crown mouldings or installations with little
clearance above the cabinet. Two required per lift mechanismset.
Item No. Angle List Ea.
83° $6.22
104° $6.22
Restricts the opening angle of the door. Prevents the door from
hitting an object above, or to keep the handle within reach on
very high cabinets.
Two required per lift mechanism set.
Item No. Angle List Ea.
75° $2.78
100° $2.78
Downloadable planning tools available at
For complete specifications order Blum catalog: .
Connects 2 stabilizer rods to
allow AVENTOS HL to be used
in cabinets up to 72" wide.
For complete specifications order Blum catalog
or visit
be used for pre-boring cabinet profiles and
BLUMOTION for doors and TIP-ON for doors
adapter plates. Calibrated scale for accurate setting. Includes
2 stop collars.
Item No. List Ea.
$219.90
Boring Template for AVENTOS SERVO-DRIVE Switch
PlateMate
Clamp assembly for secure boring of
AVENTOS SERVO-DRIVE switch.
Includes 35mmbit and two torx driver bits.
Item No. List Ea.
$721.88
75° 100°
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING &
DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
AVENTOS & LIFTS
800.533.0533 2021 1946 309 Prices subject to change without notice.
