SERVO-DRIVE Opening Feature For AVENTOS
Step 1 - Order the AVENTOS lift system (see pages 293-300 for ordering information).
Step 2 - Order the SERVO-DRIVE components for the appropriate AVENTOS system.
You will need 5-7 separate items to complete the application:
AVENTOS Lift System - (see pages 294-300)
Lift Mechanism
Telescopic Arm (HF Series only)
Hardware Set
Cross Stabilizer Rod (HL Series only)
SERVO-DRIVE System - (see pages 304-307)
SERVO-DRIVE Unit
SERVO-DRIVE Power Supply*
Cover Set
Arm Assembly Set (HL Series only)
*The power supply may power more than one unit, depending on layout.
AVENTOS lift systems open with just a light touch — and then close again with the
press of a button. An inspiring feature that is certain to impress, thanks to SERVO-
DRIVE for AVENTOS, the new electrical opening support for lift systems. After lift
mechanism installation and adjustment, SERVO-DRIVE components are attached to
the lift mechanism and cabinet.
A simple touch of the switch closes
the door. TheBLUMOTION soft-close
feature ensures silent and effortless
closing.
A light touch on the front of the cabi-
net using your hand or elbow is all it
takes to open the door. Even large
and heavy doors open effortlessly.
Completely safe - even when closing -
Even when the switch has just been pressed for closing — the closing procedure is halted immediately
if the user again reaches into the cabinet and/or an object is placed between the cabinet and the door.
Completely under control -
Even though lift systems open and close automatically, the motion can be interrupted at any time. In
addition, lift systems with SERVO-DRIVE for AVENTOS can also be easily opened and closed manually at
anytime, e.g. when there is a power outage.
Completely synchronized -
Up to three drive units can be set for synchronized motion. Synchronization is ideal for multiple cabinets
that share one wide door.
Collision avoidance -
For corner applications, it is especially important that lift system fronts do not open simultaneously. Thanks
to the “collision avoidance” function, you can set drive units so that only one front opens at a time.
For complete specifications order Blum catalog
