SERVO-DRIVE Opening Feature
For AVENTOS HF
After lift mechanism installation and adjustment,
SERVO-DRIVE components are attached to the lift mechanism and cabinet.
B
Blum distance bumpers
C
Power supply and wall
mount bracket
C
Power cord
B
Cover plate
A
Drive unit
Lift mechanism
B
SERVO-DRIVE
switch
Step 2 - Order a SERVO-DRIVE Set
Step 1 - Order the appropriate AVENTOS lift
mechanism, telescopic arm and hardware set
for your application
(see page 294).
Step 3 - Order a Cover Set
A Set includes:
Drive unit
60" universal cable
Cable connector
Cable end protector (qty 2)
Set No.
List Set
B21FA000$880.44
B Set includes:
SERVO-DRIVE cover plate (left)
Cover plate (right)
Non-handed cover cap (qty 2)
SERVO-DRIVE switches (qty 2)
Ø5 mm Blum distance bumper (qty 6)
Color: Light gray, silk white or dark gray
Set No.
List Set
B21F8020-HG$287.48
B21F8020-SW$294.00
B21F8020-TG$294.00
D Set includes:
Power supply
Wall mount bracket
Three-prong power cord
Cable connector
Cable end protector (qty 3)
Cable clips (qty 10)
19 feet universal cable
Technical information
Set No.
List Set
BZ10NE03UG10$618.12
Supplies power to a single
SERVO-DRIVE unit. Includes the
12W power supply with 44" cord.
Item No.
List Ea.
BZ10NA30UGF$228.06
For multiple lift systems
For single lift system
Step 4 - Order a Power Supply
Dark Gray
Light Gray
Silk White
11/21
Finishes
HG Light Gray
SW Silk White
TG Dark Gray
