TIP-ON for AVENTOS HK-XS Stay Lift System
Wood or Wide Aluminum Door for Panel and Face Frame Applications
Power Factor
Range
Lift No. List Ea. 1 Lift 2 Lifts
17-60 34-120 $33.96
61-112 121-224 $33.96
113-156 225-312 $33.96
Hinge Recommendation:
Order Blum free-swing 110° hinge (catalog pages 194-198).
For doors over 2' wide order 1 additional hinge per linear foot.
Calculate the power factor to determine the required lift mechanism for your application. See formula below.
Minimum Cabinet Depth = 127 mm (5")
For complete specifications order Blum catalog
B-AVENTOS-HK-XS or visit
6 separate items are required to complete unit:
Lift mechanism(s), TIP-ON mechanism, door mounting plate,
cabinetmounting plate, CLIP top free-swing hinges and baseplates.
Order screws separately.
NOTE: a pozidrive bit is required to make necessary
adjustments .
NOTE: Two lift mechanisms are required for cabinet widths
greater than 610 (24"). Opening angle is 105° with CLIP
top BLUMOTION.
Step 4 - order door mounting plates
Works for both overlay and inset applications. For door heights
greater than 400 mm use Gray nylon.
Set No. Description List Set
For standard doors $12.64
For large doors $15.82
Panel
Screw-On
EXPANDO
Face Frame
Screw-On
Item No. Description List Ea.
Panel-screw-on $4.36
Panel-EXPANDO dowel $5.66
Face Frame-screw-on $11.92
Screw-on
For large overlay 5-piece doors
Screw-On
Item No. Description List Ea.
Screw-on $3.22
Screw-on $11.24
Screws for door mounting plates sold separately
Item No. Door Description List
Wood #6x5/8" FHPH $4.64c
Aluminum #7x13mm $0.38ea
Power factor (PF) = cabinet height (") x door weight (lbs.) including twice the handle weight.
Don't know the door weight?
Call us...we can help!
Step 1 - Determine the power factor for the application
Step 2 - order lift mechanism(s)
Step 3 - order cabinet mounting plates
Step 5 - order a TIP-ON mechanism set
Step 6 - order hinges & baseplates
238 (9-3/8") - 610 (24")
door range
cabinet widths up to 1828 (72")
Screw-On Expando
Dowel
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
AVENTOS & LIFTS
