AVENTOS HK-S Stay Lift System (Small Doors)
Wood or Wide Aluminum Door for Panel and Face Frame Applications
For small wall cabinets above a
refrigerator or pantry.
Kit includes:
Lift mechanism kit , cover plates and door mounting plates. Order screws for door
mounting plates separately.
NOTE: a pozidrive bit is required to make necessary adjustments
.
Minimum Cabinet Depth =
165mm (6-1/2")
For complete specifications order Blum catalog
or visit
Mounting Plate with Bracket Set
For use with large overlay 5-piece doors on face frame application
Set includes left and right mounting
plates with brackets.
Item No. List Set
$21.80
Optional Item
Screws for door mounting plates sold separately
(4 required per set).
Item No. Door Description List
Wood #6x5/8" FHPH $4.64c
Aluminum #7x13mm $0.38ea
Power factor (PF) = cabinet height (") x door weight (lbs.) including twice the handle weight.
Don't know the door weight?
Call us...we can help!
Calculate the power factor to determine the required lift mechanism for your application. See formula below.
Note: Face frame cabinets must be blocked out flush with the frame on the sides to mount the AVENTOS HK-S lift mechanisms.
Step 1 - Determine the power factor for the application
Step 2 - order lift mechanism kit
186 (7-3/8") - 610 (24")
door range
381 (15") - 1828 (72")
Screws for door mounting plates sold separately
(4 required per set).
Item No. Door Description List
Wood #6x5/8" FHPH $4.64c
Aluminum #7x13mm $0.38ea
TIP-ON for AVENTOS HK-S see pages 303.
door mounting plates
(also sold separately.)
Kit includes
2 ea Lift mechanisms
2 ea Cover plates w/caps (R/L)
2 ea Door mounting plates (B175H3100)
6 ea #7 x 35mm (1-3/8") wood screws
Use the more powerful lift mechanism for overlapping areas.
Power
Factor
Opening
Angle Kit No.
Cover Plate
Finish List Kit
19-39* 107° B20K2B HG, SW, TG $102.00
40-85 107° B20K2C HG, SW, TG $108.66
86-177 107° B20K2E HG, SW, TG $110.18
*Spring on left mechanism only.
