Charles McMurray Co. 2023 Catalog

456h / 1645

Drawer Height: 192 mm (7-9/16").
Minimum Opening Height: 209 mm (8-1/4") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
For Interior Roll-out Drawers
Use E Height Drawer Kit + Interior Roll-out Kit
MB-E-INT (Specify color when ordering)
Kit No.
List Per Kit
Gray
(GR)
White
(WH)
$110.76 $110.76
*Specify Gray (GR) or White (WH)
BZI4.2ES1 (Set)
Interior Front Fixing Bracket
BZV4.1042M/ BZR4.1059U
Front Piece & Cross Gallery Rail
(Required for interior roll-out.)
Kit includes:
1 set Interior Front Fixing Brackets
1 ea. Front Piece
1 ea. Cross Gallery Rail
(All installation screws are included.)
(Any combination of E Height MERIVOBOX drawers can be used
with interior roll-out application. All components apart from front
fixing brackets are needed.)
05/24
Interior Roll-out Drawers
Indium Gray Silk White MERIVOBOX - E Height (7-9/16") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
E Height interior roll-out drawer with BOXCOVER
(side insert not included) (see pg. 456g for components)
E Height interior roll-out drawer with gallery rails
(see pg. 456f for components)
E Height interior roll-out drawer with BOXCAP
(see pg. 456e for components)
Optional TIP-ON BLUMOTION Units
for Touch-to-Open/Soft-Close
For more information and accessories see page 456k.
Set No.
For
Length List Set
For up to 44 lbs.
11" only $61.30
14-22" $61.30
For 44-88 lbs.
14-22" $61.30
For 88-155 lbs.
18-24" $61.30
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 456h Prices subject to change without notice.
