456g / 1645
Optional TIP-ON BLUMOTION Units
for Touch-to-Open/Soft-Close
For more information and accessories see page 456k.
Set No.
For
Length List Set
For up to 44 lbs.
BT60H414011" only $61.30
BT60H434014-22" $61.30
For 44-88 lbs.
BT60H454014-22" $61.30
For 88-155 lbs.
BT60H4570
18-24" $61.30
06/24
Standard Drawer with BOXCOVER (BOXCOVER side insert not included)
Drawer Height: 192 mm (7-9/16").
Minimum Opening Height: 209 mm (8-1/4") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Indium Gray
Silk White
MERIVOBOX - E Height (7-9/16") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
BZB4E000S (Set)
Rear Fixing Bracket
BZF4.50I2 (2 ea.)
Top Front Fixing
Bracket
BZL4M00808 (Set)
BOXCOVER
Components
BZF4.10I2 (2 ea.)
Front Fixing Bracket
B450/B453 (Set)
Cabinet Profiles
B470 (Set)
Drawer Profiles
Sold as a kit:
(Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each INSERTA Front Fixing Brackets
2 each INSERTA Top Front Fixing Brackets
1 set BOXCOVER
(All installation screws are included.)
Kit No.
Nominal
Length
Actual
Length
List Per Kit
Gray
(GR)
White
(WH)
125 lb. Load Rating
MB-E-BCOVER-270*11"
10-5/8" $163.92 $163.92
MB-E-BCOVER-350*14"
13-3/4" $154.50 $154.50
MB-E-BCOVER-400*16"
15-3/4" $155.82 $155.82
MB-E-BCOVER-450*18" 17-11/16" $157.16 $157.16
MB-E-BCOVER-500*20" 19-11/16" $158.32 $158.32
MB-E-BCOVER-550*22"
21-5/8" $167.96 $167.96
170 lb. Load Rating
MB-E-BCOVER-450-HD* 18" 17-11/16" $179.78 $173.58
MB-E-BCOVER-500-HD* 20" 19-11/16" $181.16 $174.96
MB-E-BCOVER-550-HD* 22"
21-5/8" $191.14 $184.94
MB-E-BCOVER-600-HD* 24"
23-5/8" $215.18 $208.98
*Specify Gray (GR) or White (WH)
AL = Actual cabinet profile length
Cutting BOXCOVER drawer side insert
Insert
X
Y
Z
Side AL - 90 mm
(AL - 3-1/2")
95 mm
(3-3/4")
8 mm
(5/16")
(Drawer side
insert is not
included)
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
