456d / 1645

BZI4.0MS1 (Set)
Interior Front Fixing Bracket
Item No. Description Gray (GR) White (WH)
Interior Drawer Parts
.0MS1* Int. front fixing bracket $35.80 $35.80
M* Front piece $45.24 $45.24
Fixing Brackets
Rear fixing bracket $3.16 $3.16
EXPANDO front fixing bracket $1.28
*Specify color when ordering.
BZV4.1042M
Front Piece
1042 mm (41") cut-to-size
L=inside cabinet width minus 126 (5")
H: 98.8 mm
Standard Drawer Components Interior Roll-out Components
05/24
Sold as a kit: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each INSERTA Front Fixing Brackets*
(All installation screws are included.)
*When building Interior Roll-out Drawers, use
Front Fixing Brackets included in MB-M-INT kit.
For Interior Roll-out Drawers
Use Standard Drawer Kit + Interior Roll-out Kit
MB-M-INT (Specify color when ordering)
Kit No.
List Per Kit
Gray (GR) White (WH)
$81.04 $81.04
*Specify Gray (GR) or White (WH)
Interior Roll-out Drawers Standard Drawers
Drawer Height: 91 mm (3-9/16").
Minimum Opening Height: 108 mm (4-1/4") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Drawer Height: 91 mm (3-9/16").
Minimum Opening Height: 108 mm (4-1/4") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Kit No.
Nominal
Length
Actual
Length
List Per Kit
Gray
(GR)
White
(WH)
125 lb. Load Rating
11" 10-5/8" $120.22 $120.22
14" 13-3/4" $110.80 $110.80
16" 15-3/4" $112.12 $112.12
18" 17-11/16" $113.46 $113.46
20" 19-11/16" $114.62 $114.62
22" 21-5/8" $124.26 $124.26
170 lb. Load Rating
18" 17-11/16" $129.88 $129.88
20" 19-11/16" $131.26 $131.26
22" 21-5/8" $141.24 $141.24
24" 23-5/8" $165.28 $165.28
*Specify Gray (GR) or White (WH)
BZI4.0MS1 (Set)
Interior Front Fixing Bracket
BZV4.1042M
Front Piece
(Required for interior roll-out.)
Kit includes:
1 set Interior Front Fixing Brackets
1 ea. Front Piece
(All installation screws are included.)
B450/B453 (Set)
Cabinet Profiles
B470 (Set)
Drawer Profiles
BZB4M000S (Set)
Rear Fixing Bracket
BZF4.10I2 (ea.)
Front Fixing Bracket
For TIP-ON
BLUMOTION
Units
(Touch-to-Open/
Soft-Close)
see page 456k.
Indium Gray Silk White MERIVOBOX - M Height (3-9/16") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
