456j / 1645
06/24
Sold as a kit:
(Specify color when ordering)
1 pair Outer Drawer Profiles w/Cover Caps
1 pair Inner Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 set BOXCAP
1 pair Outer Rear Fixing Brackets
1 pair Inner Rear Fixing Brackets
2 each INSERTA Top Front Fixing Brackets
4 each Screw-on Front Fixing Brackets*
*Screws not included for front fixing brackets, all other
installation screws included.
Wraparound Sink Drawer
Drawer Height: 192 mm (7-9/16").
Minimum Opening Height: 209 mm (8-1/4") includes 2 mm tilt
adjustment, based on 3 mm (1/8") clearance.
Minimum depth = actual profile length +3 mm (1/8").
Nominal length (NL) outer drawer sides - nominal length (NL) inner
drawer sides - min. 150 mm
Kit No.
Nominal
Length
Actual
Length
List Per Kit
Gray
(GR)
White
(WH)
125 lb. Load Rating
MB-E-WA-450*18" 17-11/16" $208.58 $208.58
MB-E-W
A-500*20" 19-11/16" $210.36 $210.36
MB-E-W
A-550*22"
21-5/8" $223.06 $223.06
170 lb. Load Rating
MB-E-WA-450-HD* 18" 17-11/16" $225.00 $225.00
MB-E-WA-500-HD* 20" 19-11/16" $227.00 $227.00
MB-E-WA-550-HD* 22"
21-5/8" $240.04 $240.04
MB-E-WA-600-HD* 24"
23-5/8" $268.30 $268.30
*Specify Gray (GR) or White (WH)
BZF4.1002 & BZF4.10I2
Front Fixing Bracket
(2 required per drawer*)
BZF4.5012
INSERTA Top Front Fixing Bracket
(2 required per drawer*)
BZBEM000S (Set)
Rear Fixing Bracket
BZB4M000S (Set)
Rear Fixing Bracket
B450/B453 (Set)
Cabinet Profiles
B470 (2 Sets)
Inner & Outer
Drawer Profiles
Boxcap (Set)
Components
Indium Gray
Silk White
MERIVOBOX - E Height (7-9/16") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
Optional TIP-ON BLUMOTION Units
for Touch-to-Open/Soft-Close
For more information and accessories see page 456k.
Set No.
For
Length List Set
For up to 44 lbs.
BT60H4140
11" only $61.30
BT60H4340
14-22" $61.30
For 44-88 lbs.
BT60H4540
14-22" $61.30
For 88-155 lbs.
BT60H4570
18-24" $61.30
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
Kit No.
Outer Profile Inner Profile
MB-E-WA-450/450HD B470M2S450
B470M2S350
MB-E-WA-500/500HD B470M2S500
B470M2S400
MB-E-WA-550/550HD B470M2S550
B470M2S450
MB-E-WA-600HD
B470M2S600
B470M2S450
NOTE: The inner drawer front
fixing brackets must be turned
180° for center piece assembly.
*INSERTA fixing is not possible
in combination with a center
piece.
