Sold as a kit: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each INSERTA Front Fixing Brackets
2 each INSERTA Top Front Fixing Brackets
1 pair Gallery Rails
(All installation screws are included.)
Standard Drawer with Gallery Rail
Drawer Height: 192 mm (7-9/16").
Minimum Opening Height: 209 mm (8-1/4") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Kit No.
Nominal
Length
Actual
Length
List Per Kit
Gray
(GR)
White
(WH)
125 lb. Load Rating
11" 10-5/8" $140.26 $140.26
14" 13-3/4" $130.84 $130.84
16" 15-3/4" $132.46 $132.46
18" 17-11/16" $134.12 $134.12
20" 19-11/16" $135.62 $135.62
22" 21-5/8" $147.70 $147.70
170 lb. Load Rating
MB-E-GL-450-HD* 18" 17-11/16" $150.54 $150.54
MB-E-GL-500-HD* 20" 19-11/16" $152.26 $152.26
MB-E-GL-550-HD* 22" 21-5/8" $164.68 $164.68
MB-E-GL-600-HD* 24" 23-5/8" $193.66 $193.66
*Specify Gray (GR) or White (WH)
BZF4.10I2 (2 ea.)
Front Fixing Bracket
BZB4E000S (Set)
Rear Fixing Bracket
ZF4.50I2 (2 ea.)
Top Front Fixing Bracket
B450/B453 (Set)
Cabinet Profiles
B470 (Set)
Drawer Profiles
ZR4.E (Set)
Gallery Rails
Components
Indium Gray Silk White MERIVOBOX - E Height (7-9/16") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
Optional TIP-ON BLUMOTION Units
for Touch-to-Open/Soft-Close
For more information and accessories see page 456k.
Set No.
For
Length List Set
For up to 44 lbs.
11" only $61.30
14-22" $61.30
For 44-88 lbs.
14-22" $61.30
For 88-155 lbs.
18-24" $61.30
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
