Sold as a kit: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each INSERTA Front & Top Front Fixing Brackets*
1 set BOXCAP (All installation screws are included.)
*When building Interior Roll-out Drawers, use
Front Fixing Brackets included in MB-E-BC-INT kit.
Standard Drawer with BOXCAP
Drawer Height: 192 mm (7-9/16").
Minimum Opening Height: 209 mm (8-1/4") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Kit No.
Nominal
Length
Actual
Length
List Per Kit
Gray
(GR)
White
(WH)
125 lb. Load Rating
11" 10-5/8" $157.64 $157.64
14" 13-3/4" $148.22 $148.22
16" 15-3/4" $149.98 $149.98
18" 17-11/16" $151.72 $151.72
20" 19-11/16" $152.94 $152.94
22" 21-5/8" $165.06 $165.06
170 lb. Load Rating
18" 17-11/16" $168.14 $168.14
20" 19-11/16" $169.58 $169.58
22" 21-5/8" $182.04 $182.04
24" 23-5/8" $210.30 $210.30
*Specify Gray (GR) or White (WH)
Indium Gray Silk White MERIVOBOX - E Height (7-9/16") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
BZL4.E (Set)
BOXCAP
Components
BZF4.10I2 (2 ea.)
Front Fixing Bracket
BZB4E000S (Set)
Rear Fixing Bracket
B450/B453 (Set)
Cabinet Profiles
B470 (Set)
Drawer Profiles
BZF4.50I2 (2 ea.)
Top Front Fixing Bracket
Optional TIP-ON BLUMOTION Units
for Touch-to-Open/Soft-Close
For more information and accessories see page 456k.
Set No.
For
Length List Set
For up to 44 lbs.
11" only $61.30
14-22" $61.30
For 44-88 lbs.
14-22" $61.30
For 88-155 lbs.
18-24" $61.30
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
