Charles McMurray Co. 2023 Catalog

456m / 1645

05/24
TIP-ON BLUMOTION Unit
TIP-ON BLUMOTION for MERIVOBOX
Order MERIVOBOX drawer sets separately.
See pages 456d-456h.
• Length 1118 (44-1/32") cut-to-size
• Inside cabinet width:
Minimum = 297 (11-11/16")
Maximum = 1368 (53-7/8")
• Recommended for all cabinet widths for optimal function
Item No. List Ea.
BT60L1118W $14.56
• To be used with the BT60L1118W synchronization rod
• Two needed per application
Item No. List Ea.
BT60.000D $0.94
Synchronization Adapter
(2 included with TIP-ON BLUMOTION kit)
Synchronization Rods
For narrow applications:
• Length 64 (2-1/2") cut-to-size
• Inside cabinet width: Minimum = 261 (10-1/4")
Maximum = 285 (11-1/4")
Item No. List Ea.
BT60.300D.22 $3.18
Rod length = opening width
minus 250 (9-27/32")
Rod length = opening width
minus 224 (8-13/16")
Do not use bumpers, as this
can inhibit the function of
TIP-ON BLUMOTION when
the drawer front is pressed.
3
3
2
1
1
• Enables MERIVOBOX drawers to be opened
with just a light touch of the drawer front
• Fully mechanical motion
• Smooth running action
1
2
3
Set No.
For
Length List Set
For up to 44 lbs.
11" only $61.30
14-22" $61.30
For 44-88 lbs.
14-22" $61.30
For 88-155 lbs.
18-24" $61.30
1 3
2
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
SLIDES
800.533.0533 456m Prices subject to change without notice.
