Charles McMurray Co. 2023 Catalog

459 / 1645

METABOX Steel Drawer Program
Self-Closing, 75 lbs. Dynamic, 100 lbs. Static
3/4 Extension, BLUMOTION Compatible
Features & Benefits
• Application possibilities
• Contemporary design
• Three-dimension front adjustment
• Easy can height adjustment
• Simple insertion and removal
• With BLUMATIC self-closing feature
• METABOX exceeds ANSI/BHMA requirements for a Grade 1 rating
• BLUMOTION soft-closing option available separately
Four drawer side heights available:
(N) Narrow - 54mm (2-1/8")
(M) Medium - 86mm (3-3/8")
(K) Med-High - 118mm (4-5/8")
(H) High - 150mm (5-7/8")
1. Loosen fixing screws
2. Adjust front
3. Tighten screws
1. Adjust height cam
2. Turn rail to adjust tilt
BLUMATIC Action
The BLUMATIC self-closing
action results from the angled
drawer and cabinet profiles.
320 Series single extension drawers have
an extension loss when fully opened.
Extension Loss
Complete specifications are
available at
METABOX "C15" drawers can be assembled
manually or with the METABOX drilling template
& bits & .
Side Adjustment Height & Tilt Adjustment
Blumotion for Metabox
see catalog page 465.
Boring for drawer back and
bottom (for 13 mm (1/2")
material, holes are 10 mm
(3/8") deep).
