METABOX 320K 4-5/8" Height
3/4 Extension, Self-Closing
100 lbs. Static, 75 lbs. Dynamic
BLUMOTION Compatible
White (WH) epoxy-coated steel. 5 pair per box. Includes cabinet
and drawer profiles only. Order front fixing brackets and
screws separately.
Item No. Length List Pair
400mm (16") $35.86
450mm (18") $36.48
500mm (20") $36.70
550mm (22") $39.24
Front Fixing Brackets
Clip
Screw-on
Nickel-plated steel
Clip
Press-In
Nickel-plated steel
Clip
EXPANDO Dowels
Nickel-plated steel
Screw-on
Nickel-plated steel
Press-in
Nickel-plated steel
C15
assembly
prongs
drawer profile
front fixing brackets
cabinet profile
Complete specifications are
available at
Screws
For profiles: Flathead phillips tapping #6 x 1/2"
For C15: Euro screw 11.5mm w/7mm head, POZI Drive
For brackets: Flathead phillips tapping #6 x 5/8" (MCFPT586)
Item No. Description Box List Pair
Front - Clip, Screw-On 250 $7.52
Front - Clip, Press-In* 250 $7.84
Front - Clip, EXPANDO 250 $8.64
Front - Screw-On 250 $4.68
Front - Press-In* 250 $5.44
*Use insertion ram BMZM0092.01 (special order).
