Horizontal profile
Cabinet profile/runner spacer (recommended)
06/24
Extra storage space with a built-in step allows easier
access to tall cabinets and eliminates the need for a
step-stool.
Built-in BLUMOTION and compatible with TIP-ON BLUMOTION
(heavy duty recommended) and SERVO-DRIVE.
Anti-slip safety system, activated by 18 lb. weight, securely locks
into position when extended (load rating 330 lbs.)
Weight rating for drawer under SPACE STEP is 45 lbs.
Fully customizable, SPACE STEP can be used in cabinets ranging
in height from 5-7/8" to 9-13/16" with three different toe-kick
designs (7/8" thick multi-layer board recommended.).
SPACE STEP
• Aluminum
• Cutting dimensions:
Inside cabinet width
-130
(5-1/8"), cut-to-size
• For outside cabinetwidth
≥1200
(47-1/4"), use
two profiles to prevent excessive bending
• Non-handed
• Two required per drawer
Sold per each in quantities
of 2.
Set No.
List ea.
BZ95D4100$26.14
Item No.
List Ea.
BZ95Q1040A$63.48
NOTE:
Step surface must be anti-slip. EN-14183 requires both safety labels be clearly displayed.
Recessed
Recessed low
Flush
1
TANDEM slides (561Hxxx1B95) (qty 2)
2
Vertical support (qty 2)
3
Corner connector (qty 2)
4
Support feet (qty 2)
5
Rear panel bracket (qty 2)
6
Front connector set (magnet & catch plate)
7
Spring distance bumper* (qty 4)
Safety sticker (qty 2)
Installation instructions
4mm x 15mm flathead screws
Set No.
Step Length
List Set
BZ95.410016-3/4" (425 mm)
$305.38
BZ95.460018-11/16" (475 mm) $306.32
*For outside cabinet width >35-7/16" (900 mm), four
bumpers recommended.
Set includes:
SPACE STEP set (Orion gray)
