Charles McMurray Co. 2023 Catalog

470 / 1645

Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
List Pair
50
8" $30.54 $27.38 $26.04
10" $28.80 $25.82 $24.56
12" $28.84 $25.86 $24.60
14" $28.86 $25.08 $23.90
16" $29.74 $25.84 $24.62
18" $30.64 $26.62 $24.98
20" $31.30 $27.26 $25.60
22" $32.94 $28.76 $27.04
24" $38.12 $34.18 $32.50
26" $40.00 $35.86 $34.10
28" $39.80 $35.70 $33.94
Polybagged 10 pair per box with screws (#7 x 1/2" panhead).
Item No. Length List Pair
List Pair
10
12" $37.54 $31.50
14" $38.18 $32.04
16" $39.20 $32.90
18" $40.26 $33.78
20" $41.66 $34.96
22" $44.30 $37.18
Bulk pack 10 pair per box without screws. Sold in full boxes only.
Price is per pair. Order screws separately.
Item No. Length List Pair
List Pair
10
List Pair
30
22" $51.32 $45.16 $42.60
KV8400 Series
Full Extension Box or File Drawer Slide
Side Mount - 100 lb. Load Rating
KV8400-WH White Finish
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
14" $40.60 $34.08
16" $39.16 $33.18
18" $40.04 $33.94
20" $41.68 $35.32
22" $43.46 $36.94
26" $53.28 $44.72
KV8417 Self-Closing, Stay-Closed
KV8400 Anochrome Finish
• Face frame mounting hole
• Telescopic movement on ball-bearings
• Lever disconnect for easy drawer removal
Screws
Mounting Brackets
Item No. Description Box List Pair
For KV8400 Slides
Rear Bracket 200 pr $15.24
Front Bracket 10 pr $11.24
For KV8417 Slides
Rear Bracket 200 pr $12.56
Front Bracket 10 pr $11.24
Front & Rear Set* 10 st $14.46
* Includes (2) 8403 rear brackets, (2) 8404 front brackets, screws
& installation sheet.
8404
8402 8403
#8 x 7/16", trusshead, #2 phillips,
coarse. Sold per box.
Item No. Box List Box
1c $6.12
10c $40.14
• 32 mm hole pattern with direct access mounting
• Non-handed design
• For drawers up to 24" wide
slides are
Self-closing slides use
spring technology to
close a drawer.
