Charles McMurray Co. 2023 Catalog

476 / 1645

MC4800 Series
Full Extension +1-1/2" Over-Travel
Side Mount - 100 lb. Load Rating
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
List Pair
50
14" $17.26 $15.00 $14.10
16" $19.14 $16.64 $15.62
18" $21.26 $18.50 $17.36
20" $23.22 $20.20 $18.96
• Ball-bearing progressive action
• Face frame mounting hole
• Round sided profile
• Lever disconnect
• Non-handed design
• Zinc finish
Side Clearance: 1/2" (12.7 mm)
Height: 1-13/16" (46 mm)
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $6.12
10c $40.14
Rear Mounting Bracket
Rear Mounting Bracket
100 pair per box, sold by the pair.
Item No. Box List Pair
DTC-BB-REAR-SOFT 100pr $1.14
11/24
CGS Platinum Series
Soft-Close Drawer Slide
Full Extension
Side Mount - 100 lb. Load Rating
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
12" $32.78 $28.50
14" $33.54 $29.16
16" $34.60 $30.08
18" $36.46 $31.70
20" $38.68 $33.64
22" $40.96 $35.62
24" $43.54 $37.86
Features:
• Ball-bearing carriage hold-out feature
• Stainless steel cushion-close trip-pin
mechanism (40 mm soft-closing distance)
• Heavy-gauge steel construction
• Front-levered disconnect
• 32 mm hole pattern
• 1/2" side clearance
• 100 lb. load rating
• KCMA/BIFMA tested and certified
Mounting Brackets
Item No. List Pair
List Pair
60
CGS-REAR $6.87 $5.60
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
MCAC7168-1C 1c $6.12
MCAC7168-10C 10c $40.14
12.7 ±0.2
1.3±0.2
45.3 ±0.2
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 476 Prices subject to change without notice.
McMurray.com
