Charles McMurray Co. 2023 Catalog

478 / 1645

KV4450 Soft-Close
Full Extension (12"-22")
Low Profile 36 mm (1-13/32")
Side Mount - 65 lb. Load Rating
• Face frame hole
• Clearance: 1/2" plus 1/32" each side
• Telescopic movement on precision steel ball-bearings
• Direct access mounting and adjustment
• Lever disconnect
• Flexible mounting tabs can be adjusted for slide space
variances
• For drawers up to 24" wide
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length Travel List Pair
List Pair
10
10" 7.87" $37.68 $33.16
12" 11.81" $38.50 $33.88
14" 13.78" $36.72 $32.56
16" 15.75" $37.96 $33.66
18" 17.72" $40.00 $35.48
20" 19.69" $42.46 $37.66
22" 21.65" $45.06 $39.96
1.125"
width minus 1" to 1.062"
width
1/2" min.
Item
No. Description Box List Pair
List Pair
10
List Pair
20
Rear Bracket 10pr $14.86 $13.00 $10.40
3-9/16"
1-1/2"
Mounting Brackets
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $6.12
10c $40.14
3-9/16"
1-1/2"
KV4400 Series
Full Extension, Low Profile (36 mm)
Side Mount - 65 lb. Load Rating
• Traditional and 32 mm hole patterns
• Face frame mounting hole
• Telescopic movement on precision steel ball-bearings
• Lever disconnect
• Direct access mounting and adjustment
• Flexible mounting tabs can be adjusted for slide space
variances
• For drawers up to 24" wide
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
List Pair
30
10" $24.96 $21.96 $20.72
12" $26.54 $23.36 $22.04
14" $26.04 $23.10 $21.86
16" $27.84 $24.68 $23.36
18" $29.44 $26.12 $24.72
20" $30.94 $27.44 $25.96
22" $32.12 $28.50 $26.96
Mounting Brackets
width
width minus 1" to 1.062"
1.125"
1"
1/2"
min.
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $6.12
10c $40.14
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 478 Prices subject to change without notice.
McMurray.com
Item
No. Description Box List Pair
List Pair
10
List Pair
20
Rear Bracket 10pr $14.86 $13.00 $10.40
