Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length Travel List Pair
List Pair
10
12" 10.19" $52.92 $47.26
14" 13.99" $52.92 $47.26
16" 15.99" $52.92 $47.26
18" 17.99" $52.52 $46.98
20" 19.99" $53.14 $47.54
22" 21.99" $54.00 $48.32
24" 23.99" $59.28 $52.56
26" 25.99" $60.12 $53.32
28" 27.99" $60.46 $53.62
KV8450FM Series
Soft-Close Drawer Slide
Full Extension (14"-28")
Side Mount - 100 lb. Load Rating
• Integrated patented soft-close mechanism
• Face frame mounting hole
• 32 mm hole pattern with direct access mounting
• Lever disconnect for easy drawer removal
• Non-handed design
• For drawers up to 24" wide
• Telescopic movement on ball-bearings
• Anochrome finish
Soft Close Module
Mounting Brackets
8403
Rear
Bracket
8404 Front
Bracket
Item No. Description Box List
List Full
Box
Rear Bracket 200pr $12.56pr $11.00pr
Front Bracket 10pr $11.24pr $9.84pr
Front & Rear Set* 20st $15.46st $14.46st
* Includes (2) 8403 rear brackets, (2) 8404 front brackets, screws
& installation sheet.
Screws
#6 x 1/2", low profile pan head, #2 phillips.
10c per box, sold per box.
Item No. Description List Box
Coarse Thread $45.06
slides are
KV8455FM Series
Soft-Close Drawer Slide
Full Extension +1" Over-Travel
Side Mount - 90 lb. Load Rating
• Soft-Close Module with Force Management™ Technology
• 1/2" Side Clearance, no set-up change from KV8400
or KV8450
• Traditional and 32 mm hole patterns allow for easy, flexible
installation on framed and frameless cabinetry
• Three ball-bearings per inch and polymer stop cushions aid
with smooth quiet operation of the slide
• Push-in lever disconnect allows for easy drawer removal
• Ball retainer latch and ramps allow for easy drawer insertion
• For drawers up to 24" wide
• Telescopic movement on ball-bearings
Clearance 1/2", plus 1/32" minus 0" each side; Height 1-13/16"
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
16" $57.88 $48.58
18" $58.60 $49.18
20" $59.32 $49.78
22" $56.64 $48.00
24" $60.98 $51.18
28" $62.22 $52.22
1/2" min. width minus 1" to 1.062"
1-1/8"
1"
width
Mounting Brackets
8403
Rear
Bracket
8404 Front
Bracket
* Includes (2) 8403 rear brackets, (2) 8404 front brackets, screws
& installation sheet.
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $6.12
10c $40.14
Item No. Description Box List
List
Full Box
Rear Bracket 200pr $12.56pr $11.00pr
Front Bracket 10pr $11.24pr $9.84pr
Front & Rear Set* 20st $15.46 $14.46
