Rear Mounting Bracket
100 pair per box, sold by the pair.
Item No. Box List Pair
100pr $1.14
Bulk pack 10 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
10
List Pair
50
10" $16.40 $13.68 $12.62
12" $16.62 $13.86 $12.78
14" $18.34 $15.28 $14.10
16" $17.68 $15.04 $13.98
18" $19.52 $16.58 $15.42
20" $21.46 $18.24 $16.98
22" $23.74 $20.18 $18.76
24" $29.04 $26.40 $22.34
26" $30.68 $25.56 $23.60
28" $32.60 $27.16 $25.08
*Less than full extension, see chart below right.
#8 x 7/16" coarse thread, trusshead, #2 phillips screws.
Sold per box.
Item No. Box List Box
MCAC7168-1C 1c $6.12
MCAC7168-10C 10c $40.14
Side Clearance: 1/2" (12.7 mm)
Height: 1-13/16" (45.7 mm)
NL = Nominal Slide Length
LT = Internal Cabinet Depth
Screw Positions (matches
Accuride hole pattern)
Item NL Travel A B C D E F
250 (10") 163.8 174
300 (12") 263.8 224 64 96
350 (14") 335.3 256 96 64 128
400 (16") 401 320 128 64 128 192
450 (18") 451 352 160 64 128 224
500 (20") 501 416 192 64 128 256
550 (22") 551 448 224 64 128 224 320
600 (24") 601 512 224 64 128 224 352
650 (26") 651 512 224 64 128 224 416
700 (28") 701 608 224 64 128 224 480
Installation Dimensions
• Ball-bearingmovementwith integrated soft-close
• Round sided profile
• Non-handed design
• Zinc finish
Super-Rail Soft-Close Series
Full Extension (16"-28") Drawer Slide
Side Mount - 100 lb. Load Rating
