KV8600 Series
Full Extension
File Drawer or Lateral Slide
Side Mount - 150 lb to 200 lb.* Load Rating
• 32 mm and traditional hole pattern
• Telescopic movement on ball-bearings
• Non-handed
• Butterfly lever disconnect
• For drawers up to 36" wide
*Load Rating
Weight
Max Drawer
Width Cycles
150 lbs 36" 50,000 (center-pull)
200 lbs 18" 25,000 (center-pull)
Bulk pack 5 pair per box without screws. Price is per pair.
Order screws separately.
Item No. Length List Pair
List Pair
5
List Pair
20
16" $57.50 $54.04 $48.26
18" $58.84 $55.52 $49.86
20" $63.60 $60.00 $53.90
22" $68.72 $64.84 $58.24
24" $78.12 $73.44 $65.58
26" $84.56 $79.48 $70.96
28" $90.64 $85.20 $76.08
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $6.12
10c $40.14
3/4" + .03"
3"
KV8900 Series
Extra Heavy-Duty Full Extension
Side Mount - Up to 500 lb. Load Rating
(based on application)
• Telescopic movement on ball-bearings
• Heavy-duty stops are designed to survive rough use
• Non-disconnect
• Non-handed for easy installation
Load Rating Chart (using 18" slide)
Drawer Width Load Rating
18" 500 lbs.
42" 400 lbs.
36" 300 lbs.
32" 100 lbs. flat load
_______________________________________
_______________________________________
_______________________________________
_______________________________________
Polybagged without screws. Price is per pair.
Item No. Length Box List Pair
List Pair
Full Box
16" 4 $223.86 $185.38
18" 4 $242.76 $201.04
20" 4 $257.14 $212.94
22" 3 $278.84 $230.90
24" 3 $306.56 $253.88
28" 3 $346.12 $286.62
30" 2 $373.10 $308.96
32" 2 $402.04 $332.94
34" 2 $429.66 $355.82
36" 2 $443.78 $367.50
Bulk pack without screws. Price is per pair.
Item No. Length Box List Pair
List Pair
2
40" 1 $508.86 $421.40
42" 1 $557.44 $461.62
48" 1 $709.06 $587.18
60" 1 $1,122.42 $929.50
NOTE: This slidemust never be used as
a pull-out step, platform or any other
application supporting human weight
as injury may result.
Recommended Fasteners
Use 1/4" or (M6 Euro) flat, hex, or panhead screw for
.26 (6.6 mm) cabinet member holes
Use 1/4" or (M6 Euro) hex or panhead screw for
.26 (6.6 mm) drawer member holes
Use #10 or (M5 Euro) flat, hex, or panhead screw for
.20 (5.2 mm) cabinet member holes
Use #10 or (M5 Euro) hex or panhead screw for
.20 (5.2 mm) drawer member holes
