487 / 1645
Pantry Pull-Out Slide w/Top Guide - 275 lb. each
Full Extension, Progressive Action,
Soft-Close
Width
top guides
For cabinets taller than 72" (1800 mm)
Up to 18" (450) width:
one slide is recommended
Over 18" (450) width:
two slides are recommended
Width
39.6
13
59 ±1
25
+7.5
~ 36.5 0
80
25
3
3
56
96
min. 108
3
min. 115 with Easy Close System
Applications:
Large storage applications such as: pantries, archives,
tool storage, home entertainment systems, institutional
storage, computer systems storage.
NOTE: Do not lubricate any part of the slide!
top guide
bottom slide
• No deflection in fully extended position
• Quick and easy installation
• Quiet movement, even under the heaviest loads
• Horizontal and vertical adjustment
• Top slide for absolute lateral stability
• LGA-tested according to DIN 4554 standard at 50,000 double cycles
• Back stop
• Easy Close Device (ECD) integrated (top and bottom slide)
• Powder-coated cold-rolled steel
Fasteners not included.
Sold per set. Set includes one slide and one top guide.
Set No.
Length
Extension List Set
FLT771ECD22-5/8" (575)
22" (559)
