Charles McMurray Co. 2023 Catalog

484 / 1645

• Height: 2-9/64" (54.5 mm)
• Side spacing: 1/2" (12.7 mm)
• Electro zinc finish
• Screw mounting system 32 mm compatible
• Trigger release disconnect
• Breather tab self-adjustment to accommodate variation in
side clearance
• Anti-rebound
• Non-handed
• Easy access window to reach hole in cabinet member in
closed position
• Detent - in closed position
FT200 Series
Full Extension
Side Mount - 200 lb. Load Rating at 24"
Length
(A) B C D E F G H I Load
16" (400) 11-1/4" (288) 1-5/16" (33) 6-5/16" (160) 6-5/16" (160) 8-13/16" (224) 180 lbs.
18" (450) 13-7/8" (352) 1" (25) 1-1/4" (32) 6-5/16" (160) 7-9/16" (192) 8-13/16" (224) 200 lbs.
20" (500) 13-7/8" (352) 16-3/8" (416) 1" (25) 1-1/4" (32) 7-9/16" (192) 8-13/16" (224) 8-13/16" (224) 200 lbs.
22" (550) 13-7/8" (352) 16-3/8" (416) 1" (25) 1-1/4" (32) 2-1/4" (58) 8-13/16" (224) 10-1/16" (256) 8-13/16" (224) 200 lbs.
24" (600) 13-7/8" (352) 18-7/8" (480) 1" (25) 1-1/4" (32) 1-13/16" (45) 10-1/16" (256) 10-1/16" (256) 8-13/16" (224) 180 lbs.
26" (650) 13-7/8" (352) 21-3/8" (544) 1" (25) 1-1/4" (32) 10-1/16" (256) 12-9/16" (320) 8-13/16" (224) 162 lbs.
28" (700) 13-7/8" (352) 21-3/8" (544) 1" (25) 1-1/4" (32) 3-1/4" (82) 10-1/16" (256) 13-7/8" (352) 8-13/16" (224) 145 lbs.
30" (750) 16-3/8" (416) 26-15/32" (672) 1" (25) 1-1/4" (32) 11-3/8" (288) 15-1/16" (384) 8-13/16" (224) 131 lbs.
32" (800) 16-3/8" (416) 26-15/32" (672) 1" (25) 1-1/4" (32) 2-13/16" (56) 12-9/16" (320) 15-1/16" (384) 8-13/16" (224) 118 lbs.
Bulk pack without screws. Price is per pair.
Order screws separately.
Item No. Length Box List Pair
List Pair
Full Box
16" 10 $58.52 $55.00
18" 10 $59.76 $56.38
20" 5 $64.56 $60.90
22" 5 $69.80 $65.86
24" 5 $79.36 $74.60
26" 5 $85.92 $80.76
28" 5 $92.12 $86.60
30" 5 $98.98 $93.04
32" 5 $105.50 $99.16
Screws
#8 x 7/16" coarse thread, trusshead, #2 phillips.
Sold per box.
Item No. Box List Box
1c $6.12
10c $40.14
