Charles McMurray Co. 2023 Catalog

456n / 1645

Lateral Stabilizer Bracket
1
2
Cutting:
1 Internal cabinetwidthminus 231mm (9-1/16")
2 Nominal length + 10 mm (3/8")
Additional stabilization for extra wide pullouts
Cut-to-size aluminum stabilization rod
No additional space requirement at the bottom
Set No. Runner Length List Set
270-400 (11"-16") $58.50
450-600 (18"-26") $58.50
Lateral Stabilizer Set
MERIVOBOX Components
• Used for stabilizing wide drawers and/or tall drawer fronts
• Reinforces the connection between the drawer bottom & the front
• One required per drawer, center on drawer bottom
See pg. 446 for assembly aids:
Torx Driver
POZI Driver
Universal Template and Drill Bits
Item No. Finish List Ea.
BZ96.10E1 Gray $6.50
Recommended for cabinet widths from 900-1400 mm (35-7/16" - 55-1/8")
Minimum space requirement (depth) = actual cabinet profile length + 15 mm (19/32")
05/24
