207 / 1590
Face Frame Cabinets
All 125° hinge special applications can be achieved in face frame
cabinets by blocking out behind the frame.
Inset Frameless Application
Mitered Door With Large Overlay
Trial application recommended
NOTE: Must use angle restriction clip to achieve application
Maximum Door Thickness
Abbreviations
H
= Plate height
P
= Door protrusion
S
= Side arm protrusion
T
= Door thickness
W
= Side panel width
B70T7553 B70T7553Maximum Door Overlay
Trial application recommended
125° Opening - Zero-Protrusion for Thicker Doors
Straight Arm Special Applications
1.5
11
92
°
37
19
41 max
H = 0
11.7
B = 30 max
Trial application recommended
NOTE: Must use angle restriction clip to achieve application
H
Overlay
0
14
15
16
17
18
19
3
4
5
6
7
8
B = boring distance
H
Overlay
0
36
38
39
41
25
27
28
30
B = boring distance
Reveal
4.5
3.5
2.5
1.5
0.5
3
4
5
6
7
8
B = boring distance
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Hinge
Item No.
Description List Ea. 25
BLUMOTION Soft-Close
B71B7580DPress-in
$22.04
