110° Hinges - Zero-Protrusion for Thin Doors
For Door Fronts From 8 mm - 14 mm
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Area of application and assembly recommendation
Materials Tested by Blum Min. Tightening
Torque (Nm)
Particleboard (transverse tensile strength >0.6 N/mm2) 1.5
MDF (transverse tensile strength >0.6 N/mm2) 1.5
HDF 2
HPL 2
Mineral composites 2
Granite stone 3
Quartz composite artificial stone 3
Ceramic plates 3
Blum accepts no liability for the use of the thin front attachment system in
combination with materials not listed or hardware from other manufacturers.
H Overlay P S
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 -1.5 56.5
28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 Fixed
distance=27
B=Boring Distance
H Inset Reveal P S
0 3.5 3 2.5 2 1.5 1 0.5 -1.5 56.5
23.5 24 24.5 25 25.5 26 26.5 Fixed
distance=27
B=Boring Distance
OL = Overlay
B = Boring distance
B = OL+27 (Fixed distance)
Boring dimensions
Dowel assembly
Attachment position/boring pattern
Overlay Partial/twin overlay Inset
Hinges
Item No. Description Box List Ea. List Ea. 50
BLUMOTION Soft-Close
EXPANDO T 125 $43.66 $37.00
Free-Swing List Ea. List Ea. 25
EXPANDO T 25 $37.42 $31.72
Accessories
Item No. Description Box List Ea.
List Ea.
100
8 mm Dowel w/screw 100 $8.82 $7.20
Features
• Available in BLUMOTION Soft-Close Free-Swing
• Deactivation switch for small/light doors
• Overload safety feature
• Compatible with existing CLIP mounting plates
