95° Inset Blind Corner Hinges - Max. Door Thickness 15/16"
Reveal
Reveal
33.5
40
92
S
adjust reveal
+/-2.5
+/-2
adjust gap
B
21.5
13
19 19
H
70 min.
3
Stationary panel
mounted to cabinet side,
top and bottom
Reveal
B
21.5
Reveal
13
19
H
70 min.
19 1.5
Stationary panel
spaced out thickness
of door bumper
Abbreviations
H = Plate height
P = Door protrusion
S = Side arm protrusion
W = Side panel width
Flush Door Applications Offset Door Applications
Adjustments and Clearances
Back of door is flush with stationary panel
Flush Door
Item No. Description
List Ea.
50
BLUMOTION Soft-Close
Screw-on $12.40
Press-in $12.08
INSERTA $15.54
Self-Close
Screw-on $9.82
Press-in $9.06
INSERTA $10.68
Offset Door
Item No. Description
List Ea.
50
BLUMOTION Soft-Close
Screw-on $12.40
Press-in $12.08
INSERTA $15.54
Self-Close
Screw-on $9.82
Press-in $9.06
INSERTA $10.68
(P)
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Minimum Reveal Table
3 0.1 0.3 0.4 0.5 0.9 1.3
4 0.1 0.3 0.4 0.5 0.9 1.3
5 0.1 0.4 0.4 0.5 0.9 1.3
6 0.1 0.3 0.4 0.5 0.9 1.2
7 0.1 0.3 0.4 0.5 0.9 1.2
B=
bore
dist.
16 18 19 20 22 24
T = door thickness
For door thickness greater than
24 mm a trial is recommended.
Features
• Available in BLUMOTION Soft-Close Self-Close
• Deactivation switch for small/light doors
• Overload safety feature
• Boring distance range 3 mm to 7 mm
• Press-in hinges must be inserted with knock-in tool or insertion ram (see pg. 222)
• Do not mix BLUMOTION and non-BLUMOTION hinges on same door
