Charles McMurray Co. 2021 Catalog

208 / 1590

155° Opening Zero Protrusion Hinges
Max. Door Thickness 15/16"
NOTE: 175H6xxx or 175L6600.24 recommended
Overlay Door
Angle Restriction Clips
For use with all 155° hinges.
Item No. Opening List Ea.
110° $1.78
92° $1.58
57
37 /
*47 3.2
*INSERTA
Hinge Cup Dimensions
90°
-2.3
Door Protrusion
At a 90° opening, using 0 mm plate, the door
will have -2.3 mm protrusion regardless of bor-
ing distance. Use side adjustment to increase
or decrease door protrusion.
NOTE: Use of 0 mm or 3 mm is recommended
for zero protrusion.
Minimum Reveal Table
3 0 0 0 0 0 0
4 0 0 0 0 0 0
5 0 0 0 0 0 0
6 0 0 0 0 0 0
7 0 0 0 0 0 0
8 0 0 0 0 0 0
B =
boring
dist.
16 18 19 20 22 24
T = door thickness
For door thickness greater than
24 mm see next page.
Frame
Frameless
H Overlay P S
0 14 15 16 17 18 19 -2.3 61
3 11 12 13 14 15 16 0.7 64
3 4 5 6 7 8 Fixed
distance
= 11 B = boring distance
Hinges
Item No. Description List Ea. 25
BLUMOTION Soft-Close
Screw-on $16.84
Press-in $17.10
INSERTA $19.72
Self-Close
Screw-on $12.02
INSERTA $14.74
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Abbreviations
H = Plate height
P = Door protrusion
S = Side arm protrusion
T = Door thickness
W = Side panel width
(110°) (92°)
Features
• Available in BLUMOTION Soft-Close Self-Close
• For use in cabinets with interior roll-outs
• Three-dimensional adjustment
• Deactivation switch for small/light doors
• Angle restriction clips available
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
CABINET HINGES
800.533.0533 2021 1946 208 Prices subject to change without notice.
