125° Opening - Zero-Protrusion for Thicker Doors
Max. Door Thickness 30 mm (1-3/16")
Overlay Door Angle Restriction Clip
For use with zero protrusion hinges. Gray
nylon.
Item No. Opening List Ea.
92° $1.78
Hinge
Item No. Description List Ea. 25
BLUMOTION Soft-Close
Press-in $22.04
Door Protrusion
At 90° opening, using 0 mm plate, the door will
have -1.7 mm protrusion regardless of boring
distance. Use side adjustment to increase or
decrease door protrusion.
NOTE: Use of 0 mm or 3 mm is recommended
for zero protrusion.
Minimum Reveal Table
3 0 0 0 0 0 0 0
4 0 0 0 0 0 0 0
5 0 0 0 0 0 0 0
6 0 0 0 0 0 0 0
7 0 0 0 0 0 0 0
8 0 0 0 0 0 0 0
B =
boring
dist.
19 20 22 24 26 28 30
T = door thickness
For door thickness greater than
30 mm see next page.
Frame
Frameless
H Overlay P S
0 14 15 16 17 18 19 -1.7 63
3 11 12 13 14 15 16 1.3 66
3 4 5 6 7 8 Fixed
distance
= 11 B = boring distance
H
B
overlay
11.7
T
72.5
H W
B
overlay
37
11.7
T
72.5 57
37
3.2
90°
-1.7
Abbreviations
H = Plate height
P = Door protrusion
S = Side arm protrusion
T = Door thickness
W = Side panel width
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Hinge Cup Dimensions
Features
• Available in BLUMOTION Soft-Close
• Deactivation switch for small/light doors
• For use with cabinets with interior roll-outs
• 92° angle restriction clip available
