Adjustments and Clearances Overlay Application Minimum Reveal Table
3 0.1 0.3 0.4 0.5 0.9 1.3
4 0.1 0.3 0.4 0.5 0.9 1.3
5 0.1 0.3 0.4 0.5 0.9 1.3
6 0.1 0.3 0.4 0.5 0.9 1.2
7 0.1 0.3 0.4 0.5 0.9 1.2
B=
bore
dist.
16 18 19 20 22 24
T = door thickness
For door thickness greater than
24 mm a trial is recommended.
Abbreviations
FP = Front panel thickness
D = Depth
H = Plate height
P = Door protrusion
S = Side arm protrusion
T = Door thickness
overlay
S
92
P
D
FP
H
95° Overlay Blind Corner Hinges
Max. Door Thickness 15/16"
Setback Overlay P D
27 2 3 4 5 6 27 32
32 7 8 9 10 11 22 27
37 12 13 14 15 16 17 22
3 4 5 6 7 Fixed
distance
= 9 B = boring distance
NOTE: Door overlay varies depending on
the setback position of the mounting plate.
Use the table to select the desired overlay
and cross-reference to the plate setback
and bore distance.
H Gap S
0 7 4 1 21
3 4 1 — 24
6 1 — — 27
16 19 22
FP = front panel thickness
NOTE: The door gap varies depending on the
thickness of the stationary panel and the height
of the mounting plate. Use the table to cross-
reference the plate height based on the front
panel thickness and door gap.
NOTE: Door gap can be adjusted ±2 mm
Hinges
Item No. Description
List Ea.
50
BLUMOTION Soft-Close
Press-in $16.58
Self-Close
INSERTA $14.52
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Features
• Available in BLUMOTION Soft-Close Self-Close
• Deactivation switch for small/light doors
• Overload safety feature
• Boring distance range 3 mm to 7 mm
• Press-in hinges must be inserted with knock-in tool or insertion ram (see pg. 222)
• Do not mix BLUMOTION and non-BLUMOTION hinges on same door
