Charles McMurray Co. 2021 Catalog

199 / 1590

120°+ Hinges - Max. Door Thickness 7/8"
For larger overlays (max 21mm)
H W
B
overlay
37
12.7
T
66.5
H HW
B
reveal
37
12.7
66.5
T
H
B
overlay
12.7
66.5
T
4.5
17.5 (11/16”)
0
The most common overlays for frame and frame-
less cabinets can be achieved by using the same
machine setting for hinge cup boring.
Bore ALL doors at 4.5 mm to achieve:
- 13 mm (1/2") overlay on frame cabinets and
- 17.5 mm overlay on frameless cabinets
Use hinge/plate combinations to the left.
Advantages:
- Only one machine setting for boring all doors
(4.5 mm)
- Same hinge used for both applications
(73T55xx)
Hinge: 73T55xx
Plate: any 0 plate
Same boring distance
Overlay Partial/Twin Overlay
Overlay Hinges (Straight Arm)
Item No. Description
List Ea.
50
List Ea.
250
Self-Close
Screw-on $4.06 $3.67
Press-in $3.64 $3.20
EXPANDO $4.34 $3.91
INSERTA $5.52 $4.98
Building Both Frame & Frameless Cabinets
Frame Frameless
Frameless Frameless
Overlay Hinges (Straight Arm)
Item No. Description
List Ea.
50
List Ea.
250
Self-Close
Screw-on $4.06 $3.67
Press-in $3.64 $3.20
EXPANDO $4.34 $3.91
INSERTA $5.52 $4.98
Hinge: 73T55xx
Plate: 175H6040
Frameless
Minimum Reveal Table
3 1.2 1.7 2.0 2.4 3.3
4 1.2 1.7 2.0 2.3 3.1
4.5 1.1 1.6 1.9 2.2 3.0
5 1.1 1.6 1.9 2.2 3.0
6 1.1 1.6 1.9 2.2 2.9
B =
boring
distance
16 18 19 20 22
T = door thickness
For door thickness greater than
22 mm a trial is recommended.
H Overlay P S
0 16 17 17.5 18 19 12 21.5
3 13 14 14.5 15 16 15 24.5
4.5 11.5 12.5 13 13.5 14.5 16.5 26
6 10 11 11.5 12 13 18 27.5
9 7 8 8.5 9 10 21 30.5
3 4 4.5 5 6 fixed
distance
= 13 B = boring distance
NOTE: 4.5 plate is only for use in frame
cabinets, 9 plate is only for frameless cabinets
H Reveal W S S
9
2 – – – – 16
18.5 28 5 3 2 – – 19
8 6 5 4 – 22
3 4 4.5 5 6
B = boring distance
Abbreviations
H = Plate height
P = Door protrusion
S = Side arm protrusion
W = Side panel width
H Overlay P S
9 7 8 8.5 9 10 18.5 28
3 4 4.5 5 6 fixed dis-
tance
= 13 B = boring distance
Frame
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Features
• Available in Self-Close
• Three-dimensional adjustment
• Add-on BLUMOTION available (B973A0500.01)
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
CABINET HINGES
800.533.0533 2021 1946 199 Prices subject to change without notice.
