194 / 1590
Minimum Reveal Table
3 0.5 1.0 1.8 2.7 4.3
4 0.5 1.0 1.7 2.5 3.8
5 0.5 0.9 1.7 2.4 3.4
6 0.5 0.9 1.6 2.3 3.2
7 0.5 0.9 1.6 2.2 3.0
B =
boring
dist.
16 19 22 24 26
T = door thickness
For door thickness greater than
26 mm a trial is recommended.
Features
• Available in
BLUMOTION
Soft-Close Self-Close
Free-Swing
• Deactivation switch for small/light doors
• Overload safety feature
• Press-in hinges must be inserted with knock-in tool or
insertion ram (see pg. 222)
H
B
Overlay
13
66.5
T
*
H W
B
Overlay
37
T
66.5
13
*
H
66.5
T
B
Overlay
13
*
H
H W
B
Reveal
37
66.5
T
13
*
H
Overlay
P S
0 14 15 16 17 18 12 21.5
3 11 12 13 14 15 15 24.5
4.5 9.5 10.5 11.5 12.5 13.5 16.5 26
6 8 9 10 11 12 18 27.5
9 5 6 7 8 9 21 30.5
3 4 5 6 7 Fixed dist.
= 11
B = boring distance
H
Overlay
P S
0 4.5 5.5 6.5 7.5 8.5 21.5 31
3 4 5 6 7 Fixed dist.
= 1.5
B = boring distance
H
Reveal
W P S
0
7 5 3 1 — 16
21.5 31
10 8 6 4 2 19
13 11 9 7 5 22
3 4 5 6 7
B = boring distance
Abbreviations
H
= Plate height
P
= Door protrusion
S
= Side arm protrusion
W
= Side panel width
Frameless
Frame
Overlay
Frameless
Frame
Partial/Twin Overlay
Frameless
Frame
Inset
110° Hinges - Max. Door Thickness 1"
NOTE:
For this application use a half-cranked
hinge and mounting plate
B175H5030.
*
All 35 mm and 8 mm holes must be a minimum of 13 mm deep
*
*
H
Reveal
P S
0 4 3 2 1 -
30 39.5
9 4.5 3.5 2.5 1.5 0.5 30.5 40
3 4 5 6 7 Fixed dist.
0 = -7
9 = 1.5
B = boring distance
NOTE:
4.5 plate is only for use in frame cabinets,
9 plate is only for frameless cabinets
BK = Onyx Black
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
For stock hinges see next page
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &
CLOSET
ORGANIZERS
KITCH./BATH
LIGHTING SLIDES
DOORS &
DRAWERS
LOCKS &
CATCHES
AVENTOS &
LIFTS
CABINET
HINGES
DECORATIVE
HARDWARE
CABINET HINGES
800.533.0533
2021
1946
194
Prices subject to change without notice.
