Silent and effortless, that’s how cabinet doors close with CLIP top BLUMO-
TION - regardless of the weight or closing speed.
With CLIP top BLUMOTION (soft-close integrated into the hinge), you can
now use thicker doors - up to 1" depending on the application. The new
geometry ensures that the door does not make contact with the cabinet
face even with smaller door gaps.
CLIP top BLUMOTION Soft-Close
BLUMOTION deactivation option
The BLUMOTION function can easily be deactivated on one of the hinges,
giving small or light doors the same high quality of motion.
Simply slide the switch on the hinge cup. Door must be closed once for the
deactivation to be complete. This creates a quicker, but still silent, close. BLU-
MOTION can be reactivated the same way.
Temperature Information
CLIP top BLUMOTION is designed to be used at temperatures between 62° and 82° F. Lower or higher tem-
peratures will not cause damage to the hinge; however, they will affect the closing speed. Once the temperature
returns to the suggested range, the hinge will return to its optimal closing action.
INSERTA
The INSERTA mechanism enables
tool-free fixing of the hinge to the
door. When the insertion lever is
pressed down, the dowels expand
to hold the hinge in place.
Mounting plates
CLIP top BLUMOTION works with all
current CLIP mounting plates so you
can start using this new hinge right
awaywith little change to production.
Boring pattern
The boring pattern for the hinge
cup remains unchanged for CLIP top
BLUMOTION; however, a
13 mm boring depth is
required for all three holes
(35 mm & 8 mm).
For complete specifications order Blum catalog
CLIP top BLUMOTION Black Onyx
Available in select hinges
95° Thick Door
110°
110°+
Cover Caps
Mounting Plates
