Frameless
Frame
Overlay
Minimum Reveal Table
3 0.5 1.0 1.8 2.7 4.3
4 0.5 1.0 1.7 2.5 3.8
4.5 0.5 1.0 1.7 2.5 3.6
5 0.5 0.9 1.7 2.4 3.4
6 0.5 0.9 1.6 2.3 3.2
7 0.5 0.9 1.6 2.2 3.0
B =
boring
dist.
16 19 22 24 26
T = door thickness
For door thickness greater than
26 mm a trial is recommended.
4.5
4.5
13
(1/2")
4.5
17.5 (11/16”)
0
110°+ Hinges - Max. Door Thickness 1"
For larger overlays up to 22 mm (7/8")
Frameless
Partial/Twin Overlay
Frameless
Frame
Building Both Frame & Frameless Cabinets
Hinge (73B35XX)
Plate (175H6040)
Hinge (73B35XX)
Plate (any 0 mm plate)
same boring distance
H
Overlay
P S
0 16 17 17.5 18 19 20 10 20
3 13 14 14.5 15 16 17 13 23
4.5 11.5 12.5 13 13.5 14.5 15.5 14.5 24.5
6 10 11 11.5 12 13 14 16 26
9 7 8 8.5 9 10 11 19 29
3 4 4.5 5 6 7 Fixed dist.
= 13
B = boring distance
NOTE:
4.5 plate is only for use in frame cabinets,
9 plate is only for frameless cabinets
H
Overlay
P S
9 7 8 8.5 9 10 11 19 29
3 4 4.5 5 6 7
Fixed
distance
= 13
B = boring distance
H
Reveal
W P S
9
2 — — — — — 16
19 29
5 3 2 — — — 19
8 6 5 4 — — 22
3 4 4.5 5 6 7
B = boring distance
The most common overlays for frame and
frameless cabinets can be achieved by using
the same machine setting for hinge cup boring.
Bore all doors at 4.5 mm to achieve:
13
(1/2") overlay on frame cabinets
17.5
(11/16") overlay on frameless cabinets
Advantages:
One machine setting for boring all doors
Same hinge used for both applications
Abbreviations
H
= Plate height
P
= Door protrusion
S
= Side arm protrusion
W
= Side panel width
H W
B
Overlay
37
T
66.5
13
*
H
H
W
B
Reveal
37
13
66.5
T
*
H
B
Overlay
13
66.5
T
*
*
All 35 mm and 8 mm holes must be a minimum of 13 mm deep
BK = Onyx Black
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
H W
B
Reveal
13
66.5
T
*
Frameless
For stock hinges see next page
Features
• Available in
BLUMOTION
Soft-Close Self-Close
Free-Swing
• Deactivation switch for small/light doors
• Overload safety feature
• Press-in hinges must be inserted with knock-in tool or
insertion ram (see pg. 222)
