Charles McMurray Co. 2021 Catalog

201 / 1590

Thick door – twin application
Special Applications - (Trial application recommended)
170° Hinges - Max. Door Thickness 15/16"
Overlay Hinges (Straight Arm)
Item No. Description
List Ea.
25
List Ea.
125
Self-Close
Screw-on $8.94 $7.82
Press-in $9.18 $8.03
INSERTA $12.30 $10.76
Free-Swing
Screw-on $9.52 $8.56
INSERTA $13.02 $11.71
Partial Overlay Hinges (Half-Cranked)
Item No. Description
List Ea.
25
List Ea.
125
Self-Close
Screw-on $12.92 $11.62
Press-in $13.18 $11.86
INSERTA $15.76 $14.19
Used to limit the opening angle of the Blum
170° wide angle hinges to 130°.
Item No. Box List Ea.
250 $2.10
Reduces overlay by 3mm. Mounts under
CLIP plates. Gray nylon.
Item No. Box List Ea.
50 $0.84
Angle Restriction Clip 3 mm (1/8") Spacer
Thick door application
Straight-Arm Applications
Half-Cranked Applications
Z = gap
15.5 13 11 9.5 7.5
25 29 32 35 38
T = door thickness
Minimum Reveal Table
0 6.5 14.5 21
22 25 29 32
T = door thickness
130°
lip
T
Z
B=5
straight-arm
hinge
37
11
H = 0
max. protrusion 65
130°
H = 0
B=5
11
37
min. reveal
T
19 19
straight-arm
hinge
130°
46
11
9
B=11 9.5
9.5
19 7
3.5 lip detail
half-cranked
hinge
max. protrusion 74
H = 3
130°
37
19
11
17
19
restriction
clip
H = 3
2
2
half-cranked
hinge
max. protrusion 78
NOTE: The above applications can be achieved in face frame cabinets by blocking out behind the frame
Lip door application Mitered corner door application
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
