H Overlay P S
0 14 15 16 17 18 14.5 22
3 11 12 13 14 15 17.5 25
4.5 9.5 10.5 11.5 12.5 13.5 19 26.5
6 8 9 10 11 12 20.5 28
9 5 6 7 8 9 23.5 31
3 4 5 6 7 Fixed dist.
= 11 B = boring distance
NOTE: 4.5 plate is only for use in frame cabinets, 9
plate is only for frameless cabinets
H Overlay P S
0 4.5 5.5 6.5 7.5 8.5 24 31
3 4 5 6 7 Fixed dist.
= 1.5 B = boring distance
H Reveal W P S
0
7 5 3 1 — 16
24 31 10 8 6 4 2 19
13 11 9 7 5 22
3 4 5 6 7
B = boring distance
Abbreviations
H = Plate height
P = Door protrusion
S = Side arm protrusion
W = Side panel width
Features
• Available in BLUMOTION Soft-Close Self-Close Free-Swing
• Deactivation switch for small/light doors
• Overload safety feature
• Press-in hinges must be inserted with knock-in tool or insertion ram
(see pg. 222)
• Do not mix BLUMOTION and non-BLUMOTION hinges on same door
H
B
Overlay 13
66
T
* *
Frameless
Frame
Overlay
Frameless
Frame
Partial/Twin Overlay
Frameless
Frame
Inset
NOTE:Forthisapplicationuseahalf-crankedhinge
and mounting plate
H W
B
Overlay
37
13
T
66
*
H H W
B
Reveal
37
13
66
T
*
Overlay Hinges (Straight Arm)
Item No. Description
List Ea.
50
BLUMOTION Soft-Close
Screw-on $9.16
Press-in $9.40
INSERTA $10.38
INSERTA $13.84
Self-Close
Screw-on $4.58
Press-in $4.82
INSERTA $6.28
Free-Swing
Screw-on $4.80
Press-in $5.02
* All 35 mm and 8 mm holes must be a minimum of 13 mm deep
Inset Hinges (Full Cranked)
Item No. Description
List Ea.
50
BLUMOTION Soft-Close
Screw-on $10.04
Press-in $10.28
INSERTA $11.78
Self-Close
Press-in $5.68
INSERTA $6.98
Free-Swing
Screw-on $5.44
Partial Overlay Hinges (Half-Cranked)
Item No. Description
List Ea.
50
BLUMOTION Soft-Close
Screw-on $9.94
Press-in $10.18
INSERTA $11.68
Self-Close
INSERTA $6.94
Free-Swing
Screw-on $5.32
*
*
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
Minimum Reveal Table
3 0.4 0.8 1.0 1.5 1.9 2.8 3.6
4 0.4 0.7 1.0 1.4 1.8 2.5 3.1
5 0.4 0.7 1.0 1.4 1.8 2.3 2.7
6 0.4 0.7 1.0 1.4 1.8 2.2 2.5
7 0.4 0.7 0.9 1.4 1.7 2.1 2.4
B =
boring
dist.
19 22 24 26 28 29 30
T = door thickness
For door thickness greater than
30 mm a trial is recommended.
H Reveal P S
0 4 3 2 1 - 32.5 40
9 4.5 3.5 2.5 1.5 0.5 33 40.5
3 4 5 6 7 Fixed dist.
0 = -7
9 = 15 B = boring distance
